Elsyca Xplorer

Elsyca Xplorer

Interactive simulation results viewer

More info Contact us

Elsyca XPlorer

A free to download solution allowing you to interactively display by Elsyca computed project results on any computer.


Elsyca XPlorer is an interactive simulation results viewer. It was specifically designed to share the 3D simulation results with the end-user/customer. While a report provides static graphical information on layer thickness and current density distribution, Elsyca XPlorer enables the user to interactively interrogate the simulation results for further analysis.

Key Benefits

Free

Fee-of-charge and stand-alone application that does not require any third-party components/software;

Fast and Robust

Very fast and robust, specifically developed to display results from electrochemical simulations

Key features

Versatile

Rotate, pan, zoom in and out, hide part(s), switch between different simulation results (e.g. layer thickness, current density), change scale,... All you need to get immersed in your results.

Control your display

Display the simulated value on any area (mouse click or hover) or on probe lines, save / load layouts

Easily compare and optimize

Possibility to run several Elsyca XPlorer applications simultaneously, making it very easy to compare different simulation results and experimental results.

Contact us for more information or a personalized quotation.
